lightweight
alloy frame
26" x 4"
tyres
7 Speed Shimano
Drivetrain
Alloy Frame
Fat tyre bikes can be heavier than regular bikes – but we try our best to minimise the weight with a lightweight alloy frame. A lighter frame also helps in creasing agility and handling of your bike, essential for any ride.
Adventure On with No Limits
Running 26” by 4” wide Fat Tyres, the Cracker is designed to handle terrain that would be impossible on a regular bike. The big footprint of a fat bike tyre distributes load over a bigger area & provides excellent traction on climbs or even cornering.
Riding on Clouds
Fat Tyres will make you feel like you’re floating over terrain. Rough terrain with rocks and roots that would normally rattle your brains on a regular bike, will be barely felt under the crush of Cracker’s big 26" x 4" tyres.
7 Speed Shimano Drivetrain
Using a quality Shimano drivetrain, the Shimano Tourney Group set provides reliable shifting for 7 Speeds, so you’ll be able to maintain cadence and the right gear ratio for any terrain.
Strong Stopping Power
Strong, reliable stopping power is paramount to any bike rider, especially if you're manoeuvring through tough terrain. That's why our Cracker comes with Disc brakes for consistent, high-powered braking performance.
- Rim Brakes (like Caliper or V Brakes) can be unreliable in wet or muddy conditions
- Longer lasting
- Stronger braking performance
- Less adjustment and maintenance required
The Blueprints
An awesome package with the following components:
- A. Alloy Frame
- B. Quick Release Adjustable Seat-post
- C. Big 26” x 4” Fat Tyres
- D. Shimano 7 Speed Drivetrain
- E. Big MTB Kickstand for soft, muddy terrain
- F. Front & Rear Disc Brakes
Where to ride?
Specification
Technical Specifications
| Frame Sizes | 17" |
|---|---|
| Frame |
Alloy 26" — 432mm, Head Tube 38 34 150mm
RC 475mm BB 112mm Width:190mm |
| Fork | Steel 26" 28.6 25.4 30 240mm, Width:135mm |
| Handlebars | XC-932,steel, matt black,W:650mm,R:30mm |
| Grips | TC-G07 black rubber L/R:125/92mm |
| Stem | XC-HS088A 25.4x 28.6 alloy black EXT:90mm,17° |
| Seatpost | SP-200 steel ED black 27.2x300mm |
| Seat Clamp | YC02 YC122 alloy black 31.8mm |
| Saddle | XF-1059, black |
| Pedals | FP-803 black plastic 9/16" W/ball AS |
| Gear Shifters | Shimano Tourney ASLTX30R7AT TX30 7S index, casing:2050mm |
| Rear Derailleur | Shimano Tourney RD-TY300 steel ED black 7SPD,W/OB |
| Front Brakes | F:JAK-5,disc brake |
| Rear Brakes | R:JAK-5,disc 160mm, R:M6x16mm |
| Brake Levers | L/R:BV316DG alloy black clamp/silver lever |
| Freewheel | AMFTZ217428T TZ21 7SPD 14-24T brown 28T black |
|---|---|
| Chainwheel | GS-S144-A05 1/2*3/32*36T steel ED black W/CG leg:L:170mm alloy |
| Chain | Z50x114L brown |
| Bottom Bracket | XR-BB04 steel ED black, 167.5mm |
| BB | FPT-9C(50.5 60 54.5) |
| Headset | XR-W10,steel ED black |
| Front Hub | SF-HB30F 12Gx36Hx135x175mmx(3/8") Steel ED black |
| Rear Hub | SF-HB30R 12Gx36Hx7SPDx195x240mmx(3/8") steel ED black |
| Spokes | 12G steel UCP |
| Tyre | 26x4.0" F178 all black |
| Tube | 26"x4.0" A/V |
| Rim | P85D 26"x12Gx36H, alloy black, single wall 85MM, A/V |
| Bell | JNDDL-3501 steel CP black clamp |
| Kickstand | J04-142 26" 10mm |
| Box Dimension | 156x23x76 (LxWxH, cm), 17kg |
| Bike Weight | 14kg |
| Seat Height | Max: 93cm (Seat to ground) |
Bike Size Guide
| Frame Size Number | 17" |
| Wheel Size | 26" |
| Suggested Height | 175-195cm |
| Minimum Suggested Inseam | 75cm |
| A - Seat Tube | 43.2cm |
| B - Seat Tube Angle | 72deg |
| C - Head Tube Length | 13cm |
| D - Effective Top Tube | 57.2cm |
| E - Chainstay length | 45cm |
| F - Wheelbase | 107cm |
| G - Standover | 70cm |
